AURA XL V1 24V
AURA FAMILY modules are designed to deliver uniform and powerful backlighting for light boxes and channel letters ranging from 2 to 12 inches in depth.
Wattage:
Voltage:
CCT:
Application Areas
Office: Light Box, Channel Letter, Stretch Ceiling.
In case of additional questions - please ask below:
Our lighting designers and sales engineers are ready to support your project specifications.
Due to the constant renewal of our model range and improving technical characteristics the technical information can slightly differ from the latest version. To receive the most up-to-date technical information for project development please refer to your LT Company manager.
Technical Specifications
Technical Data
| Module Dimension | 83.9mm x 13.5mm x 9.7mm |
| Beam Angle | 170 Degree |
| SDCM | <3 |
| CRI | >80 |
| CCT | 3000K/4000K/6500K/8000K/10000K/R/G/B |
| Life of LED L80/B10 | 50000 Burning Hours |
| Warranty | 5 Years |
| Ingress Protection | IP67 |
| Operating Temperature at Tc | -10 to 60 Deg C |
| Storage Temperature | 0-65 Deg C |
| Dimming Compatible | Yes |
Features
- Built-in technology prevents module overheating or burning, ensuring long-term reliability and safety.
- Specially designed wide lens technology for maximizing light coverage area.
- Easy installation with pre drilled holes or industrial grade 3M tape for mounting.
- LM79, LM80, BIS, CE compliance certificates available on request.
Application Areas
Light Box, Channel Letter, Stretch Ceiling.
