RIGID S
Shine bright
RIGID is a surface floor mounted IP67 linear luminaire for applications creating unbreakable light line.
Colors:
Wattage:
CCT:
Application Areas
Office: OUTDOOR:- Facade Lighting
Product Configuration / Application Images
In case of additional questions - please ask below:
Our lighting designers and sales engineers are ready to support your project specifications.
Due to the constant renewal of our model range and improving technical characteristics the technical information can slightly differ from the latest version. To receive the most up-to-date technical information for project development please refer to your LT Company manager.
Technical Specifications
Technical Data
| Lumen maintenance | L70 @ 50K Hours |
| Photo biological Safety | RG0 |
| Electrical Insulation Class | Class 1 |
| IP Rating | IP67 |
| Surge rating | 20KV with SPD |
| Driver Placement | Non Integral |
| Driver Type | Constant Voltage |
| Rated I/P Voltage | 24 VDC |
| IK Rating | IK 08 |
| Operating ambient Temp | 0 to 50 Degree C |
| MacAdam Value | <5 SDCM |
Features
- UV Resistant silicon potted diffused optics for uniform distribution
- Corrosion resistance with special Powder coated finish using Nano Technology.
- Compatible with High efficiency Non Integral 24V DC CV Driver placed inside IP BOX.
- Inbuilt separate Trunk for carrying cables and Loop in Loop Out ensuring neat & clear installation
Application Areas
OUTDOOR:- Facade Lighting
